High-speed, fully enclosed vertical grinding mill equipped with an integrated Air Classifier for dust-free, continuous, high-efficiency grinding across Chhattisgarh and Odisha.
Select your equipment type and requirements to instantly find the right model for your operations.
Actual capacity and power requirements vary by model and grind material type. Please contact us for the exact configuration and current availability.
Engineered for maximum output, durability, and a completely dust-free working environment.
What it is: High-speed, fully enclosed vertical grinding mill equipped with an integrated Air Classifier.
Business Benefit: Dust-free operation with continuous, high-efficiency grinding and automated fine-powder separation.
Build Quality: Constructed from heavy-duty cast iron with top covers bolted together. Internal surfaces are lined with FSSAI Compliant high-grade Stainless Steel 304 (SS 304) plates.
Business Benefit: Easy access for inspection; inner steel lining prevents machine wear, significantly extending lifespan.
Mechanism: Shaft-driven gear mechanism with built-in feed speed control.
Business Benefit: Ensures a smooth, continuous flow of raw material into the grinding chamber without overloading or manual feeding effort.
Protection: Lined with replaceable, ultra-hard chilled iron liner plates.
Business Benefit: Protects the main chamber against severe wear and tear from hard materials, making the core structure virtually everlasting.
Design: Heavy-gauge machined mild steel plates on a precision-machined, solid alloy steel shaft.
Business Benefit: Delivers continuous high-torque performance without bending or vibration under heavy loads.
Components: Double-row, self-aligning ball bearings housed in heavy cast iron with dedicated grease cups.
Business Benefit: Smooth performance under continuous heavy load, preventing bearing failure and overheating.
Quality: Drop-forged alloy steel hammers, precision-balanced for smooth rotation.
Business Benefit: Extreme impact strength for hard minerals and spices, reducing frequent hammer replacements.
Capability: Adjustable classifier blades that allow output adjustment up to 300 mesh fine powder.
Business Benefit: Complete flexibility to adjust powder fineness based on buyer demand across different materials.
Design: Paddle-type heavy blower with easily replaceable blades and arms.
Business Benefit: Maintains strong air flow to pull ground material smoothly out of the chamber, preventing clogging.
Design: Fully welded mild steel sheet cyclone separator. Top-and-bottom sheet housing fitted with durable cotton filter bags.
Business Benefit: Captures maximum finished product with minimal powder loss, keeping the factory floor clean and safe.
Structure: Heavy-duty mild steel piping with loose flange joints.
Business Benefit: Quick and simple installation, effortless dismantling, and hassle-free routine cleaning.
Features: Dedicated Oil Cups and Grease Cups on all critical bearing points.
Business Benefit: Simple daily maintenance keeps running costs low and ensures non-stop production.
Detailed breakdown of components and construction materials.
| Type | Vertical Model Air Swept totally enclosed, high-speed swing hammer type grinding mill with Whizzer Air Classifier. |
| Body | The main body is made of Heavy-Duty Cast iron, machined with Top covers bolted together for easy opening and clearing or for inspection. Every portion in the machine, which comes in contact with the material, is lined with high-grade steel plates. |
| Feeder | Automatic rotary feeder gear driven from the main shaft with feed control mechanism. |
| Crushing Chamber | The striking face of the Crushing Chamber is lined with hard chilled iron replaceable. Plates keeping in view of the proper protection to be given to the chamber from the wear and tear which ensures ever-lasting. |
| Rotor | Thick mild steel machined plates mounted on main shaft. |
| Shaft | Solid heavy duty alloy steel of proper dimension. |
| Bearings | Best Double row self-aligning Ball Bearings in cast iron housing with suitable Grease Cups for heavy duty lubrication. |
| Hammer | Forged alloy steel, and perfectly balanced. |
| Classifier | Mild Steel Whizzer Classifier with changeable blades and adjustable spiders to control fineness of ground powder up to 300 mesh depending on the type of material to be pulverised. |
| Blower | Heavy duty peddle type with changeable blades and arms (Impellers). |
| Cyclone | Mild Steel Sheet fabricated, welded throughout cones. |
| Dust Collector | Top and bottom halves of Mild Steel Sheet to be interconnected by Cotton Cloth dust bags. |
| Pipes | All interconnection Mild Steel Pipes are supplied with loose Flanges to facilitate easy erection, opening, and clearing. |
| Lubricants | All bearings are provided with Oil Cup, Grease Cup for heavy Lubrication. |
